salt-marsh-mapping

UMass UAS Salt Marsh Project salt marsh land cover mapping

salt-marsh-mapping is a special-purpose package for the vegetation mapping component of the UMass UAS Salt Marsh project. This project uses UAS (Unoccupied Aerial Systems), a.k.a “drones,” with a number of sensors, along with field transects to drive vegetation cover models at several salt marshes in Massachusetts.

This package supports modeling for this project. It is intended to be run on the UMass Unity cluster using slurmcollie, although all functions may be run locally if needed.

This documentation is a work in progress.

Installation and set up

Install the package and dependencies

# install.packages("devtools")
devtools::install_github('UMass-UAS-Salt-Marsh/salt-marsh-mapping')
devtools::install_github('UMassCDS/slurmcollie')                                    # a companion package required for running batch jobs on Unity
devtools::install_github('bwcompton/batchtools', ref = 'bwcompton-robust-sbatch')   # while waiting for pull request

Authorize Google Drive

If you’ll be getting data from the Google Drive with gather, you’ll need get an authorization token. This needs to be done only once for each user. Run the following from the Unity account you’ll be using:

set_up_google_drive()

Processing sequence

Here’s a brief summary of the processing sequence. See the help for each function for details. An example sequence will be created soon. All of these are normally launched as batch jobs on Unity via slurmcollie (except for screen which is intrinsically interactive and speedy assess).

  1. gather Gather the data from the source (either Google Drive or SFTP)
  2. screen build the flights database and open a web app to allow visually assigning quality scores to each image.
  3. derive Create derived images, such as NDVI (Normalized Difference Vegetation Index), upscaled images, and canopy height estimates from the difference between mid-summer and early spring DEMs.
  4. sample Sample images at points where we have field-collected data, creating a data table for modeling.
  5. fit Build statistical models of vegetation cover with random forests, AdaBoost (planned), or potentially other modeling frameworks and report model assessment.
  6. map Produce geoTIFF maps of predicted vegetation cover.

Additional functions

  • fitinfo Displays information from the fits database on one or more fits, including model specification, assessment, and run statistics such as CPU and memory use. Can also be used to save an Excel-friendly text version of the fits database and to set assessment scores and comments.
  • mapinfo Displays information from the maps database, including model used for each map and run statistics such as CPU and memory use. Can also be used to Can also be used to save an Excel-friendly text version of the maps database and set map scores and comments.
  • assess Provide a model assessment. This is normally included in fit, but assess may be called separately to assess the fit of a model built on one or more sites and applied to other sites.
  • flights_report Creates a report on on orthoimages for all sites, including a summary for each site, a list of files flagged for repair in screen, a list of duplicated portable names for each site, and a list of all files for each site.
  • build_flights_db Builds the flights database for a site, necessary after new files are downloaded with gather. This is normally called by screen when you first view a site, so there’s no need to call it manually unless you are unable or unwilling to run screen.
  • find_orthos(site, descrip) Returns a data frame of file names and portable names matched by one or more file names, portable names, search names, or regular expressions of file names or portable names for a given site. You can use this to refine name designations and be sure you’re getting what you want.

slurmcollie functions

See slurmcollie for details.

  • info() Shows the status of jobs you’ve launched
  • showlog(job) Shows the log of a running or finished job
  • kill(jobs) Kill one or more jobs you didn’t mean to launch
  • purge(jobs) Purge jobs that have finished or failed once you no longer care about them

Image naming

UAS images (orthophotos, DEMs, canopy height models, and derived variables) may be referred to in three different ways. Functions that take imagery names as arguments (gather, derive, sample, and fit) use find_orthos to resolve all three of these name types, as well as regular expressions of file names and portable names. Use find_orthos to try out name designations.

File name

This is the file name assigned during image processing. Filenames usually encode the image’s date, site, tide level, sensor, and type, for instance 19Aug22_OTH_Mid_SWIR_Ortho.tif or 14Oct20_OTH_Low_Mica_DEM.tif. File names are somewhat inconsistent, for instance, the month may be Sep or Sept, years may be 2 or 4 digits, and some sensors are referred to by multiple names. Additionally, some filenames follow a wildly different pattern, such as OTH_Aug2022_CHM_NoThin_5cmTriNN_NAD83.tif, a canopy height model. Files are imported from the source repositories (either Google Drive or SFTP) with their names unmodified, except that file names that start with a digit have an x prepended, thus 14Oct20_OTH_Low_Mica_DEM.tif becomes x14Oct20_OTH_Low_Mica_DEM.tif. (File names beginning with a digit can lead to downstream problems in R, as they are invalid variable names).

When using derive to create derived images (for example, NDVI or mean upscaling), derived names are generated from the base name (or names), with derivation information separated with a double underscore, e.g., x20Jun22_OTH_Mid_Mica_Ortho__NDVI.tif. See derive for details.

These file names are unsuitable for use in modeling because they include the site code and the exact date of the flight, both of which would break any attempt to build a model on one or more sites and apply it to others. The name inconsistencies also make them difficult to use.

Portable name

Portable names are generated by build_flights_db (which is called to update the flights database whenever you run screen, so if you’re visually screening all images in a normal process you won’t need to worry about this). Portable names exclude the site, use seasons instead of an exact date, and force naming consistency.

Portable names for most images consist of:

<type>_<sensor>_<season>_<year>_<tide>[-tidemod][_<derive>[-<window>]]

The portable names for canopy height models are simply:

chm_<source>_<year>, where source is either lidar or delta.

Here are examples of file names and portable names

File name Portable name
19Aug22_OTH_Mid_SWIR_Ortho.tif ortho_swir_summer_2022_mid
14Oct20_OTH_Low_Mica_DEM.tif dem_mica_fall_2020_low
OTH_Aug2022_CHM_NoThin_5cmTriNN_NAD83.tif chm_summer_2022
x20Jun22_OTH_Mid_Mica_Ortho__NDVI.tif ndvi_mica_spring_2022_mid
x01Aug20_OTH_MidOut_Mica_Ortho.tif ortho_mica_summer_2020_mid-out
OTH_Aug2022_CHM_NoThin_5cmTriNN_NAD83.tif chm_lidar_2022
x26May22_RR_Low_Mica_DEM__x19Aug22_RR_Low_Mica_DEM.tif chm_delta_2022

Portable names are used for variable names in data files created by sample, and they’re the names you’ll see in model assessments. You can find the portable name for each file in data/<site>/flights/flights_<site>.txt. The portable name is displayed in the screen app.

In cases where portable names refer to two or more image files (because two identical site/type/sensor/tide flights were flown in the same season), the image with the highest score will be used. Remaining ties will be broken by taking the earliest matching image.

Search name

Finally, search names allow model fits to refer to multiple files in an easily-readable format. The components of a search name are separated with vertical bars (note these are pretty separators, NOT logical or–the parts of a search name are conjunctive). Multiple values of a component are separated with commas, or a colon to select a range for ordinal values such as season or year. Modifiers (in, out, and spring for tides; window size for upscaled variables) are separated from the component with a dash, e.g., mid-out. Components in a search name may appear in any order. Each component in the search name narrows the search, thus mica | low, mid matches any files with a Mica sensor that are at low or mid-tide. Here are some example search names:

mid-in, mid-out, high
mica, swir, p4 | ortho | high-spring | spring:fall | 2019:2022
mica, swir | ortho, dem | low:high | spring | 2018

Search names allow model fits to be described clearly and concisely, even for models that contain dozens of variables, as they often will.

See help(search_names) for details.
